● PC/104
● Number of Inputs: Eight
● Type: Non-polarized, optically-isolated from each other and from the computer. (CMOS compatible).
● Voltage Range: 3 to 31V DC or AC RMS (50 to 10 KHz)
● Isolation: 500V
● Input Resistance: 1.8KΩ in series with opto-coupler.
● Response Time: 4.7 milliseconds w/filter, 10usec w/o filter
● Number of Inputs: Eight
● Type: TTL, 10K pull up to 5V
● Purpose: For reading dry contact closures or any TTL compatible outputs
● Number of Outputs: Eight
● Type: SPDT Form C Relay – Omron G5V-1
● Contact Ratings: 1A @ 24VDC (60VDC max), 0.5A @ 125VAC carry current
● Contact Type: Single crossbar Ag with Au clad (bifurcated contacts optional)
● Contact Arrangements: Channels 0-7: SPDT Form C
● Contact Resistance: Initial, 100 mΩ maximum
● Contact Life: Mechanical: 5 million operations minimum
● Operating Time: 5 milliseconds maximum
● Release Time: 5 millisecond maximum
● Regulatory Approvals: UL and CSA
● When enabled by software, interrupts are generated when any isolated digital input changes state (High to Low or Low to High, and from signal to no signal with AC inputs).
● +5VDC at 0.4A (all relays ON)
● Ambient Temperature: Operating: -30°C to 70°C. (non-icing)
● Weight: Approx. 4 oz. (~115 grams)
● This product is designed to be in full compliance with CE requirements.
