● Channels: 4, 8, or 16
● Type: Non-polarized, optically isolated from each other and from the computer (CMOS-compatible)
● Voltage: 3 to 31VDC or AC RMS (40 to 1000Hz)
● Isolation: 500V channel-to-ground and channel-to-channel (see manual)
● Response Times:
- Filtered: 4.7ms rise and fall
- Non-Filtered: 10μs rise; 30μs fall
● Channels: 4, 8, or 16
● Type: High-Side Power MOSFET Switch. Protected against short-circuit, over-temperature, ESD, and can drive inductive loads.
● Voltage Range: 5-34VDC recommended for continuous use. 40VDC absolute max. (customer supplied)
● Current Rating: 2A max
● Turn-on time: 90μS typical
● Turn-off time: 110μS typical
●thernet 10/100 Base T, Auto-detecting, 1.5kV Isolation
● Operating Temperature Range: 0°C to 70°C (Optional -40°C to +80°C)
● Storage Temperature Range: -40°C to +85°C
● Humidity: 5%-90%, non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 4.00 x 4.00 x 1.7 inches
● Connectors:
- Isolated Inputs: Dual row 0.1” 34-pin
- Relay Outputs: Dual row 0.1″ 50-pin
- DC power jack: 2.0mm + center post
- Screw terminals: Available via enclosure cutout
● External AC/DC 5V regulated power is required
● 5V @ 35mA plus 5mA per energized FET; 5V @ 115mA with all FETs on, typical
