● ISA Bus
● Logic High: 2.0 to 5.0 V DC.
● Logic Low: -0.5 to +0.8 V DC.
● Input Load (Hi): 20 uA.
● Input Load (Lo): -200 uA.
● Logic High: 2.5 VDC min., source 15 mA.
● Logic Low: 0.5 VDC max., sink 24 mA. (64 mA optional)
● Operating Temperature Range: 0° to 60°C.
● Storage Temperature Range: -40° to +100°C.
● Humidity: 0 to 90% RH, non-condensing.
● Size: 7.15 inches. Install in a half-length slot.
● Input: +5 VDC at 300 mA typical
● Output: +5 VDC from computer bus (ext. 1A fast-blow fuse recommended).
● This product is designed to be in full compliance with CE requirements.
