● PCI Bus
● Serial Ports: Two shielded male D-sub 9-pin connectors compatible with RS-485 and RS-422 specifications.
● Serial Data Rates: Up to 115,200 baud, asynchronous. A faster range of rates, up to 460,800 baud, is achieved by jumper selection on the card.
● Asynchronous Communication Element: Type 16550 UART which includes 16-byte FIFO.
● Receiver Input Sensitivity: ±200 mV differential input.
● Common Mode Voltage Rejection: +12V to -7V.
● Transmitter Output Drive Capability: 60 mA.
● Operating Temperature Range: 0 to +60°C.
● Storage: -25 to +85°C
● Humidity: 0 to 90 percent (non-condensing)
● Power Required: +5VDC at 125 mA typical, +12VDC at 5 mA typical, 750 mW total power consumption.
● Size: 6.15″ long (156mm) by 3.875″ high (98mm)
● This product is designed to be in full compliance with CE requirements.
