● PCI Express
● Number of inputs: 8
● Type:Non-polarized, optically isolated from each other and from the computer. (not TTL/CMOS compatible)
● Voltage Range: 5 to 24V DC or AC (50 to 1000 Hz)
● Isolation: 500V*(see manual) channel to channel and channel to ground
● Input Resistance: 470 ohms in series with two diodes and an LED
● Response Time: 10 mSec w/filter, 20 uSec w/o filter
● Number of outputs: 8
● Contact Rating: 2A carry current, bifurcated, gold clad, silver palladium
● Contact Arrangement: Channels 0-4 are SPDT Form C and channels 5-7 are SPST Form A.
● Contact Rating: Initial 100 milliohms maximum
● Contact Life: mech’l: 5 million operations minimum; elect’l: 5 million operations minimum at full load
● Operating Time: 2 milliseconds maximum
● Release Time: 1 milliseconds maximum
● Regulatory Approvals: UL and CSA
● Interrupts enabled by software, generated when digital inputs change state
● Back Panel DB37 Male
● +5VDC @ 0.675 A (all relays ON) for PCIe-IIRO-8
● Operating Temperature 0° to +70°C
● Storage Temperature -40° to +105°C
● Humidity 5% to 95% RH, without condensation
● Weight: Approx. 8 oz. (227 grams)
● Size: PCIe-IIRO-8 is 6.6″ (168 mm) long
● This product is designed to be in full compliance with CE requirements.
