● High-speed USB 2.0 device, USB 3.0 and 1.1 compatible
● 48 lines of digital I/O
● 24 fully protected and isolated FET 2A outputs
● High retention type B USB connector
● Mini USB header connector in parallel with type B for stacking and embedded applications
● Six (6) 8-bit ports independently selectable for inputs or outputs
● All I/O lines buffered with 32 mA source, 64mA sink current capabilities
● I/O Buffers can be enabled or tri-stated under program control
● Drivers and sample application provided
● Jumper selectable I/O pulled up to 5V for contact monitoring, pulled down to ground or floating in 8-bit groups
● Jumper selectable power provided via USB cable or external power supply for higher source current capabilities
● Resettable fused +5VDC outputs per 50-pin connector
● Standard 50-pin IDC-type shrouded connectors with key
● Removable internal terminal board for ease of wiring
● PC/104 module size and mounting compatibility (3.550″ by 3.775″)
● Rugged, industrial, steel enclosure
● Compatible with industry standard I/O racks like Grayhill, Opto 22, Western Reserve Controls, etc.
● Labview VI driver
● Now with Firmware 2.0 features!
- Onboard Watchdog Timer, configurable power-on defaults, digital input debouncing and latching, digital output Pulse Width Modulation (PWM) and Matrix Mapping
● FACTORY OPTIONS：
- 24 I/O, 12 FET output version
- 24 FET output only version
- OEM (board only) version for embeddeed applications
- External power components and regulated AC/DC adapter
● Extended operating temperature (-40° to +85°C)
● Screw terminals for power input provide high retention connection
● RoHS Available. Please contact us for ordering information
● Support for Wind River VxWorks
● Process Monitoring
● Manufacturing/Production Test
● Mobile Solutions
● Test Equipment
● Kiosks
● Robotics
● Machine Control
● Monitoring and Control
● Security Systems, Energy Management
● Relay Monitoring and Control
● Sensing Switch Closures or TTL, DTL, CMOS Logic
● Driving Indicator Lights or Recorders
● Industrial Automation
● Embedded OEM
Available accessories include a DIN-Rail mounting adapter, model MP104-DIN. Also available is our low cost IIB-24 which will add optical isolation to any standard 24-channel digital input port on a 50 pin connector. To make use of the miniature embedded USB header connector, we offer a variety of embedded OEM USB cables. Additional accessories include flat ribbon cables and other DIN-rail mountable screw terminal boards for remote wiring and installation.
Isolate your I/O with our USB-ISOLATOR accessory! Tru-Iso? signal isolation up to 4kV meets EN60601 standards in a rugged industrial-grade, extended temp (-40 to +85°C) package — no connection to power needed! Use with our 1-foot USB cable and avoid tangles. OEM-version available, featuring picoblade microfit headers for hassle-free embedded cabling.
