● Number: Sixteen
● Type: Non-polarized, optically isolated from each other and from the computer (CMOS compatible)
● Voltage: 3 to 31 DC or AC RMS (40Hz to 10kHz)
● Isolation: 500V* (see manual) channel-to-ground and channel-to-channel
● Resistance: 1.8K ohms in series with opto-coupler
● Filter Response: Rise Time = 4.7 mS / Fall Time = 4.7 mS
● Non-Filter Response: Rise Time = 10 uS / Fall Time = 30 uS
● Number: Sixteen solid state FETs
● Output Type: Low-side power MOSFET switch. Protected against short circuit, over-temperature, ESD, and can drive inductive loads.
● Voltage Range: (customer supplied) 5-42VDC recommended for continuous use.
● Current Rating: 500mA maximum
● Turn-on time: 90uS (typical)
● Turn-off time: 110uS (typical)
● Universal Serial Bus: USB 2.0 high-speed, USB 1.1 full-speed compatible
● Operating Temperature 0° to +70°C, optional -40° to +85°C
● Storage Temperature -40° to +85°C
● Humidity 5% to 95% , non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 4.00 x 4.00 x 1.4 inches
● +5VDC provided via USB bus cable up to 500mA**
● +5V @ 35mA typical (all FETs off, add 5mA per FET)
● +5V @ 115mA typical (all FETs ON)
**Optional on-board external power circuitry and AC/DC adapter can be ordered (“-P” option) if current use is expected to be greater than what can be supplied by the USB bus. Please check to see how much current your USB port can supply and how much current you anticipate using.
● This product is designed to be in full compliance with CE requirements.
