● Number: Sixteen
● Type: Non-polarized, optically isolated from each other and from the computer (CMOS compatible)
● Voltage: 3 to 31 DC or AC RMS (40Hz to 10kHz)
● Isolation: 500V* (see manual) channel-to-ground and channel-to-channel
● Resistance: 1.8K ohms in series with opto-coupler
● Filter Response: Rise Time = 4.7 mS / Fall Time = 4.7 mS
● Non-Filter Response: Rise Time = 10 uS / Fall Time = 30 uS
● Number: Sixteen SPDT form C
● Contact Type: Single crossbar; Ag with Au clad
● AC Load: 0.5 A at 125 VAC (62.5 VA max.)
● DC Load: 1A at 24 VDC (30 W max.)
● Switching Voltage: 125 VAC, 60 VDC max.
● Switching Current: 1A max.
● Contact Resistance: 100 mOHM max
● Contact Life: mech’l: 5 million operations min.
● Operating Time: 5 msec max.
● Release Time: 5 msec max.
● Operating Temperature 0° to +70°C, optional -40° to +85°C
● Storage Temperature -40° to +85°C
● Humidity 5% to 95% , non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 4.00 x 4.00 x 1.4 inches
● 5V@ 30mA typical (all relays off, add 30mA per relay)
● 5V@ 510mA typical (all relays ON)
● +5VDC provided via USB cable up to 500mA**
**optional external power supply can be ordered if relay use of the USB-IIRO-16 is expected to be greater than what can be supplied by the USB cable.
● This product is designed to be in full compliance with CE requirements.
